Product Range

Commercial Framing // Aluminium Glazing Channels

Introduction

Alspec® offers a range of Glazing Channels to meet your building and design requirements.

Alspec's® Channels can be used as standard perimeter Glazing Channel applications or recessed Glazing Channel applications and come in a range of sizes from 25mm to 44mm to accommodate single or double glazed requirements.

Alspec's® Aluminium Glazing Channel range can accept from 4mm to 12mm glass for single glazed, 24mm to 28mm double glazed when glazing with wedges and 12mm to 19mm when silicone glazing.

Gallery

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

Frame Dimensions
Option 1 25 x 25mm
Option 2 30 x 30/45mm
Option 3 30 x 32/45mm
Option 4 44 x 35mm
Glazing Details
Glass Position Centre
Single Glazed 4 - 12mm
Double Glazed 24 - 28mm
Maximum Recommended Sizes
Height 2400mm
Width 2400mm
