Commercial Framing // ecoFRAMEplus 76mm Centre Pocket Double Glazed Framing

Introduction

The ecoFRAMEplus® is the ideal system principally when energy efficiency is paramount. Its versatility allows countless specifications to be achieved, from standard shopfront applications, through to the most challenging structural and energy requirements.

With a frame depth of 76mm x 45mm, ecoFRAMEplus® allows a frame to transform from double to single glazed with ease. Glazing could not be simpler with the colour coded wedges to deal with the many diverse glass options.

Sub sills are recommended for optimum weathering with all ecoFRAMEplus® systems.

Projects

Coming Soon

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Glazing
Frame
TVW
Air Inf
Frame Dimensions
Option 1 76mm x 45mm
Maximum Product Performance
SLS (Pa) 670
ULS (Pa) 2130
WATER (Pa) 1000
Glazing Details
Glass Position Centre
Single Glazed 4 - 14mm
Double Glazed 16 - 18mm
Compatible Systems
Windows & Doors Swan Evo 45mm Commercial Shopfront Door
Windows & Doors 35mm Awning Window
Windows & Doors View-Max Commercial Sliding Window
Windows & Doors Altitude Apartment Sliding Door
Maximum Recommended Sizes
Height 3000mm
Width 1200mm
WERSNatspec

Tested and Compliant Solutions
