Commercial Framing // McArthur 101.6mm Centre Pocket Framing

Introduction

The McArthur Centre Pocket Glazing System is the most popular and flexible of the Alspec® Commercial range. With a frame depth of 101.6mm x 44.4mm it is ideal for shopfront use and is widely favoured by architects and designers for a multitude of applications.

With it's straight cuts and centre pocket glazing the McArthur not only looks good, but is easy to fabricate and easy to install.

McArthur is suitable for a range of glass thicknesses with self draining sub sills that solve water leakage problems.

The McArthur also provides a seamless interface with Alspec's extensive product offer.

Features & Benefits

  • Sharp unbroken lines
  • Robust frame
  • Excellent weathering
  • 4mm up to 10.38 glazing options
  • Centre pocket framing, reducing the number of beads required thus improving fabrication and installation time
  • Various adaptors to easily accept awnings, double hung, sliding windows, louvres and Alspec's extensive door range


Videos

Projects

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Glazing
Frame
TVW
Air Inf
Frame Dimensions
Option 1 101.6 x 44.5mm
Maximum Product Performance
SLS (Pa) 4000
ULS (Pa) 4800
WATER (Pa) 1500
Compatible Systems
Windows & Doors Torrens
Windows & Doors Swan Evo
Windows & Doors 35mm Awning
Windows & Doors 50mm Awning
Windows & Doors ProTilt Awning
Windows & Doors View-Max
Windows & Doors ProGlide
Windows & Doors Altitude
Glazing Details
Glass Position CENTRE
Single Glazed 4 - 10.38mm
Acoustic Performance: Rw (c;ctr)
6.38mm Laminate 33 (-1,-2) dB
10.38mm/12/6.38mm IGU 33 (-1,-2) dB
Maximum Recommended Sizes
Height 4200mm
Width 2200mm
Thermal Performance
Uw range SG 4.2 - 6.1
SHGC range SG 0.32 - 0.76
WERSNatspec

Tested and Compliant Solutions
