Commercial Framing // McArthur 150 Offset Pocket Framing

Introduction

Alspec’s McArthur 150 Offset Pocket Framing is an extension of Alspec’s® popular and widely used McArthur Centre Pocket Framing. Which is widely favoured by architects and designers for a multitude of applications.

Available in a frame depth of 150mm x 44.4mm the McArthur 150 Offset Pocket Framing is perfect for nesting such items as roller blinds and other shading systems within its frame. It also integrates with the smaller 101.6mm transom offering the structural requirements needed in the mullions and the ability to keep your project on budget.

Use as a standalone 150mm Offset Pocket Framing system or with the McArthur 101.6mm Centre Pocket Framing where it is important to keep the external appearance of the framing.

With it's straight cuts and offset pocket glazing the McArthur 150 Offset Pocket Framing not only looks good, but is easy to fabricate and easy to install. McArthur 150 Offset Pocket is suitable for a range of glass thicknesses up to 10.38mm with self draining sub sills that solve water leakage problems. The McArthur also provides a seamless interface with Alspec's extensive product offer.

Gallery

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

Frame Dimensions
Option 1 150 x 44.5mm
Maximum Product Performance
SLS (Pa) 3200
ULS (Pa) 5300
WATER (Pa) 1000
Glazing Details
Glass Position Offset
Single Glazed 4 - 10.38mm
Acoustic Performance: Rw (c;ctr)
6.38mm Laminate 33 (-1,-2)
Max Glass 33 (-1,-2) 6.38mm
Maximum Recommended Sizes
Height 4800mm
Width 2200mm
Compatible Systems
Windows & Doors Swan
Windows & Doors Torrens
Windows & Doors Swan Evo
Windows & Doors 35mm Awning
Windows & Doors 50mm Awning
Windows & Doors ProTilt Awning
Windows & Doors ProGlide
Windows & Doors Altitude
WERSNatspec

Tested and Compliant Solutions
