Commercial Framing // McArthur Evo 150mm Centre Pocket Framing

Introduction

The McArthur Evo Centre Pocket Glazing System is the most popular and flexible of the Alspec® Commercial range. Available in two frame depths, 101.6mm and 150mm x 44.4mm. Ideal for shopfront use, it is widely favoured by architects and designers for a multitude of applications.

With it's straight cuts and centre pocket glazing the McArthur not only looks good, but is easy to fabricate and easy to install. McArthur is suitable for a range of glass thicknesses with self draining sub sills that solve water leakage problems. The McArthur also provides a seamless interface with Alspec's extensive product offer.

Projects

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Glazing
Frame
TVW
Air Inf
Frame Dimensions
Option 1 150 x 44.5mm
Maximum Product Performance
SLS (Pa) 3000
ULS (Pa) 7400
WATER (Pa) 900
Glazing Details
Glass Position Centre
Single Glazed 6 - 14.5mm
Acoustic Performance: Rw (c;ctr)
6.38mm Laminate 32 (-1,-2) dB
Maximum Recommended Sizes
Height 5100mm
Width 2400mm
Compatible Systems
Windows & Doors Swan Evo 45mm Commercial Shopfront Door
Windows & Doors Torrens 45mm Commercial Shopfront Door
Windows & Doors 35mm Awning Window
Windows & Doors 50mm Awning Window
Windows & Doors ProTilt High Performance Awning/Casement Window - Single Glazed
Windows & Doors View-Max Commercial Sliding Window
Windows & Doors ProGlide High Performance Sliding Door
Windows & Doors Altitude Apartment Sliding Door
