Hunter Evo 101.6mm Acoustic Framing
The Hunter Evo 101.6mm Acoustic Framing is the ideal system when sound reduction is paramount. Featuring dual 19mm glazing pockets with a 50mm airspace.
Tested and Compliant Solutions
The Hunter Evo 101.6mm Acoustic Framing is the ideal system when sound reduction is paramount. Featuring dual 19mm glazing pockets with a 50mm airspace, the Hunter Evo Acoustic Frame is ideal for commercial shopfronts, showrooms and high end residential projects. The Hunter Evo 101.6mm Acoustic Framing also comes with a 101.6mm x 25mm Internal Partition Frame to meet the slimline aesthetic requirements for Internal Partition demands.
Featuring straight cuts and flush glazing the Hunter Evo Acoustic Frame not only looks good, but is easy to fabricate and install. Providing a seamless interface with the Hunter Evo Flush Glazed Framing system as well as accepting 35mm and 50mm awning sashes, this system offers the flexibility and performance demanded for modern build environments.
Key Features
- Superior acoustic performance
- Sharp unbroken lines
- Flush glazed appearance
- Robust frame
- Good weathering
- Glass type include 6mm up to 14mm
- Easily adapts to Alspec’s awnings and hinged doors
Technical Specifications
Glazing Details
| Glass Position | Front / Back |
| Double Glazed | 6 - 14mm (x2) |
Compatible Systems
| Windows & Doors | Awning and Casement Windows |
| Windows & Doors | ProVista™ Sashless Double Hung Window |
| Windows & Doors | Dualair® |
| Windows & Doors | ProGlide® High Performance Sliding Door |
| Windows & Doors | Altitude® Apartment Sliding Door |
Acoustic Performance: Rw (c;ctr)
| External 6.38 / 58mm Air / 6.38 | 43 (-2,-7) dB |
| External 12.5 / 50mm Air / 12.5 | 49 (-2,-5) dB |
| External 12.38 / 54mm Air / 6.38 | 45 (-1,-4) dB |
| External 12.5 / 54mm Air / 6.38 | 47 (-1,-5) dB |
| Internal Partition 6.38 / 58mm Air / 6.38 | 42 (-2,-7) dB |
| Internal Partition 12.76 / 50mm Air / 12.76 | 49 (-1,-5) dB |
| Internal Partition 12.76 / 50mm Air / 10.38 | 47 (-2,-6) dB |
| Internal Partition 12.76 / 50mm Air / 12.38 | 47 (-1, -4) dB |
Maximum Recommended Sizes
| External | 3600mm (H) x 2200mm (W) |
| Internal Partition | 3600mm (H) x 1500mm (W) |
Maximum Product Performance
| SLS (Pa) | 1700 |
| ULS (Pa) | 5800 |
| WATER (Pa) | 1000 |
