Hunter Evo 101.6mm Single Flush Glazed Framing

The most versatile and flexible of the Alspec® Commercial Framing Systems it is ideal for shopfronts and low-rise curtain wall applications.

DOWNLOAD BROCHURE WERS Rating

Tested and Compliant Solutions

BAL40

Cyclonic

Acoustics Compliant

AS2047 Compliant

The Hunter Evo 101.6mm Single Flush Glazed Framing is the most versatile and flexible of the Alspec® Commercial Framing Systems. Available in a frame depth of 101.6mm x 50mm, it is ideal for shopfronts.

With it’s straight cuts and flush glazing the Hunter Evo not only looks good, but is easy to fabricate and easy to install. Suitable for a range of single glazed glass thickness options to address the most demanding energy requirements. With self draining sub sills it also solves water leakage problems. The system can be internally or externally glazed along with incorporating the flexibility and appeal of gently curved or faceted frame installations. The Hunter Evo also provides a seamless interface with Alspec’s® extensive product offer.

Key Features

Sharp unbroken lines
Flush glazed appearance
Robust frame
Good weathering
4mm – 14mm single glazed
Easily adapts to Alspec’s awnings and hinged doors

Frame Dimensions

Option 1

101.6 x 50mm

Maximum Product Performance

SLS (Pa)	3500
ULS (Pa)	8900
WATER (Pa)	1200

Compatible Systems

Windows & Doors	Swan Evo™ 45mm/70mm Commercial Shopfront Door
Windows & Doors	Torrens 45mm Commercial Shopfront Door
Windows & Doors	Awning and Casement Windows
Windows & Doors	ProTilt® High Performance Awning/Casement Window
Windows & Doors	ProGlide® High Performance Sliding Door
Windows & Doors	Altitude® Apartment Sliding Door

Cyclonic Performance

Glass Type	12.4 mm Gen II
Speed (m/sec)	38
Glass Type	14.08mm Ultra Forza
Speed (m/sec)	38

Glazing Details

Glass Position	Front
Single Glazed	4 - 14mm

Acoustic Performance: Rw (c;c^tr)

4mm Toughened	29 (-1,-3) dB
6mm Toughened	32 (-1,-2) dB
6.38mm Laminate	33 (-1,-3) dB
6.5mm Acousta	34 (-1,-3) dB
10.38mm Laminate	34 (-1,-3) dB
10.5mm Acousta	36 (-1,-3) dB
12.38mm Laminate	36 (-1,-3) dB
12.5mm Acousta	37 (-1,-3) dB
