Commercial Windows & Doors // ProTilt® High Performance Awning/Casement Window

Introduction

Alspec's ProTilt High Performance Awning and Casement Windows are ideally suited for suburban housing, multi-unit residential, hotels and commercial applications.

Featuring overlapping internal and external seals, the ProTilt Awning and Casement Window is the preferred choice where superior weather performance is required.

A range of glass thickness options from 4mm to 28mm allows the system to be configured for excellent thermal and acoustic performance.

The system can be used with a range of available stays while also offering multi-point locking options and a proprietary operator. The ProTilt seamlessly interfaces with Alspec’s McArthur Evo and Hunter Evo Commercial Framing Systems.

Gallery

Videos

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Maximum Recommended Sizes - Awning
Without Multi-Point Locks Max height: 1500mm
Min height: 400mm
Max width: 1200mm
Min width: 500mm
Max area: 1.8m2
Max weight: 80kg
With Multi-Point Locks Max height: 2000mm
Min height: 900mm
Max width: 1500mm
Min width: 500mm
Max area: 2.4m2
Max weight: 130kg
Maximum Product Performance
SLS (Pa) 3500
ULS (Pa) 8900
WATER (Pa) 1000
Cyclonic Performance
Glass Type 12.4mm Gen II
m/sec 38
Maximum Recommended Sizes - Casement
Dual Arm With Multi-Point Locks Max height: 2100mm
Min height: 900mm
Max width: 1000mm
Min width: 500mm
Max weight: 49kg
Max area: 2.0m2
Single Arm With Multi-Point Locks Max height: 1800mm
Min height: 900mm
Max width: 700mm
Min width: 350mm
Max weight: 25kg
Max area: 1.3m2
Acoustic Performance: Rw (c;ctr)
6.38mm Laminate 33 (-1,-2) dB
6.38mm | 12 | 6.38 IGU 36 (-1, -3) dB
Compatible Systems
Commercial Framing McArthur Evo 101.6mm Centre Pocket Framing
Commercial Framing ecoFRAMEplus 101.6mm Centre Pocket Double Glazed Framing
Commercial Framing Hunter Evo 101.6mm Single Flush Glazed Framing
Commercial Framing Hunter Evo 101.6mm Double Flush Glazed Framing
Commercial Framing Hunter Evo 150mm Single Flush Glazed Framing
Commercial Framing Hunter Evo 150mm Double Flush Glazed Framing
Glazing Details
Single Glazed 4 - 16mm
Double Glazed 24 - 28mm
Thermal Performance
Uw range SG 5.4 - 6.4
SHGC range SG 0.27 - 0.49
Uw range DG 3.9 - 4.7
SHGC range DG 0.21 - 0.45
  • Invisi-Gard
  • KidScreen
  • BetterVue
WERSNatspec

Tested and Compliant Solutions
