View-Max® Commercial Sliding Window
This window offers unparalleled levels of flexibility allowing designers and architects to cater for both the slimline applications and those of a more robust commercial design.
Tested and Compliant Solutions
Maximum View – Unlimited Possibilities
The View-Max® window offers unparallel levels of flexibility by allowing designers and architects the choice of 76mm (Derwent) or 101.6mm (McArthur) framing to cater for both the slimline applications and those of a more robust commercial design.
The View-Max® window offers the flexibility of single and double glazing options. The View-Max® integrates a number of design initiatives unique to Alspec® such as the proprietary locking, roller and drainage systems.
Developed specifically for multi-storey residential and architecturally designed housing View-Max® windows offer superior weather, thermal and acoustic performance.
Key Features
- Commercially designed to suit 76mm and 101.6mm
- Developed specifically for multi-storey residential, schools and architecturally designed housing
- 4mm up to 10.38mm monolithic glass and up to 18mm double glazed units
- Superior thermal and acoustic performance (refer to test reports) • Superior weather performance
- Minimal processing, cost effective and simple fabrication
Technical Specifications
Frame Dimensions
| Option 1 | 76 x 35mm |
| Option 2 | 101.6 x 44.5mm |
Maximum Product Performance
| SLS (Pa) | 2000 |
| ULS (Pa) | 6000 |
| WATER (Pa) | 600 |
Compatible Systems
| Commercial Framing | Derwent 76mm Centre Pocket Framing |
| Commercial Framing | McArthur 101.6mm Centre Pocket Framing |
| Commercial Framing | ecoFRAMEplus 101.6mm Centre Pocket Double Glazed Framing |
Glazing Details
| Single Glazed | 4 - 10.38mm |
| Double Glazed | 18mm |
Acoustic Performance: Rw (c;ctr)
| 6.38mm Laminate | 31 (-0,-2) dB |
| 10.38mm Laminate | 32 (-1,-2) dB |
Maximum Recommended Sizes
| Height | 1600mm |
| Width | 1200mm |
| Weight | 50kgs |
Thermal Performance
| Uw range SG | 4.7 - 6.6 |
| SHGC range SG | 0.28 - 0.69 |
| Uw range DG | 3.2 - 4.4 |
| SHGC range DG | 0.16 - 0.6 |
