Products / Commercial Windows & Doors

Air-Flo^® Plus 125mm Framing

Air-Flo® Plus 125mm Framing system is a stand alone framing system offering architects and designers the latest in energy efficient ventilation.

DOWNLOAD BROCHURE WERS Rating

The Air-Flo® Plus 125mm Framing system is purposely designed to provide a total solution for all residential and commercial applications, including fixed lights and hinged doors.

The Air-Flo® Plus 125mm Framing French Door from Alspec® is a 40mm wide panel consisting of an 85mm face as standard. An integrated barrier/security door rebate allows for an overall frame size of 125mm.

Also integrable with the Swan Evo or Torrens 45mm commercial panel to cater for larger panel sizes.

Suited towards the suburban housing and multi-unit residential market, the Air-Flo® Plus 125mm Framing system caters to timber reveals, various coupling, 4-point locking, screening solutions and a full range of glazing options up to 25mm double glazed.

Successfully tested for compliance with Australian Standards AS2047, achieving high acoustic and WERS energy ratings.

Specifying Alspec’s Air-Flo® Plus 125mm Framing ensures the client receives a solid, durable high-performance product.

Read moreRead less

Key Features

Framing options compatible with French/Hinge door integration
A complete integrated screened frame offering external security and flyscreen options including Invisi-Gard®
Suitable for suburban housing and multi-unit residential market
Suitable to a range of terrain conditions
Various glazing options for energy compliance
Integrated timber reveal provision to suit various construction types

Frame Dimensions

Option 1	125 x 32mm
French Door	Width 40mm

Acoustic Performance Rw (c;ctr)

6.38mm Laminate

30 (-1,-2) dB

Compatible Systems

Commercial Windows & Doors	Swan Evo™ 45mm/70mm Commercial Shopfront Door
Commercial Windows & Doors	Torrens 45mm Commercial Shopfront Door

Glazing Details

Glass Position	Centre
Single Glazed	4 - 10.38mm
Double Glazed	18 - 25mm

Maximum Product Performance

SLS (Pa)	1500
ULS (Pa)	2780
French Door Water (Pa)	200

Maximum Recommended Sizes

Height	3600mm
Width	1100mm
French Door Height	2400mm
French Door Width	1200mm
French Door Weight	50kgs

Thermal Performance

Uw range SG	3.1 - 5.9
SHGC range SG	0.17 - 0.58

Tech Manual

Log in to view all files

Customer Technical Memos

Log in to view all files

Wall Charts

Log in to view all files

CAD Drawings

Log in to view all files

3D Revit

Log in to view all files

Download Brochure

Window ID	Glazing	Frame	U_w	SHGC_w	T_vw	Air Inf

316 Stainless Steel Security Screening Range Window Fall Prevention Screening for Kids General Flyscreen and Insect Screening Range Security, Privacy & Strength, Corrosion Resistant & Looking Great Security Screening Solution for Australia Conditions

Gallery

1

/

4

Projects

Perched atop Springbrook Mountain, Cloudview is a sublime example of how architecture can seamlessly integrate with the natural world.

Whether it’s dance, drama, visual or media arts, all now have a place to be explored in this new arts centre at this Queensland primary school.

The 700 students at this growing Queensland college can now meet as one, thanks to the completion of a new multi-purpose sports and meeting facility.

This new educational facility is a light and welcoming learning environment for senior students at this Queensland college.

Adding large panelled sliding doors and modern windows have given a light and spacious feel to this remodelled WA home.

This functional home embraces the sub-tropical seaside environment to offer a diverse range of open plan living and relaxation spaces for this NSW family.

Our commercial doors and windows are the perfect solution for the environmental challenges presented by this beautiful coastal location.

Discover the elegance of Alspec products showcased in a luxurious residential home in Queensland.
