Commercial Windows & Doors // Altitude® Sliding Window
Introduction
The Altitude Sliding Window offers unparalleled views and wide opening to invite fresh air.
Designed with top of the range sliding adjustable wheels which create minimal friction along an aluminium track.
Locking system is designed to be slimline within the stile.
The Altitude Sliding Window has an option to use stacking configurations to help create even wider openings with single or double glazed options available.
Can accommodate multiple of performance features such as security screen, flyscreen and low lights.
This Sliding window is modern, stylish and is available in multiple different colours.
| Frame Dimensions | |
| Option 1 | 76 x 46mm |
| Option 2 | 101.6 x 46mm |
| Option 3 | 150 x 46mm |
| Maximum Product Performance | |
| SLS (Pa) | 2800 |
| ULS (Pa) | 3700 |
| WATER (Pa) | 525 |
| Compatible Systems | |
| Commercial Framing | McArthur Evo Centre Pocket Framing |
| Glazing Details | |
| Single Glazed | 4 - 12.4mm |
| Double Glazed | 18mm |
| Acoustic Performance (as Per The Altitude Sliding Door) Rw (c;ctr) | |
| 6.38mm Laminate | 32 (-2,-2) dB |
| 10.38mm/12/6.38mm IGU | 36 (-0,-2) dB |
| 6.38mm/6/6.38mm IGU | 34 (-1,-3) dB |
| Maximum Recommended Sizes | |
| Height | 1800mm |
| Width | 1500mm |
| Weight | 160kg |
| Thermal Performance | |
| Uw range SG | 4.8 - 4.9 |
| SHGC range SG | 0.36 - 0.40 |
| Uw range DG | 3.6 - 4.2 |
| SHGC range DG | 0.23 - 0.57 |
