Commercial Framing // Hunter Evo 150mm Acoustic Framing

Introduction

The Hunter Evo 150mm Acoustic Framing is the ideal system when sound reduction is paramount. Featuring dual 19mm glazing pockets with 100mm airspace, the Hunter Evo Acoustic Frame is ideal for commercial shopfronts, showrooms and high end residential projects.

Featuring straight cuts and flush glazing the Hunter Evo Acoustic Frame not only looks good, but is easy to fabricate and install. Providing a seamless interface with the Hunter Evo Flush Glazed Framing system as well as accepting 35mm and 50mm awning sashes, this system offers the flexibility and performance demanded for modern build environments.

Gallery

Projects

Coming Soon

Please log in to access this information

Please log in to access this information

WERS Ratings

Frame Dimensions
Option 1 150 x 50mm
Maximum Product Performance
SLS (Pa) 3000
ULS (Pa) 4000
WATER (Pa) 500
Glazing Details
Glass Position FRONT/BACK
Double Glazed 6 - 14mm (x2)
Acoustic Performance: Rw (c;ctr)
10.38mm/12/6.38mm IGU 48 (-1,-4) 12.5 Hush/6.38mm dB
Maximum Recommended Sizes
Height 4500mm
Width 2400mm
Compatible Systems
Windows & Doors 35mm Awning
Windows & Doors 50mm Awning
WERSNatspec

Tested and Compliant Solutions
