Products / Commercial Framing

McArthur Evo 101.6mm Centre Pocket Framing

The most popular and flexible of the Alspec® Commercial range, the 101.6mm frame depth is ideal for shopfront use and is widely favoured by architects and designers for a multitude of applications.

DOWNLOAD BROCHURE WERS Rating

Tested and Compliant Solutions

BAL40
Acoustics
Compliant
AS2047
Compliant
Cyclonic

The McArthur Evo Centre Pocket Glazing System is the most popular and flexible of the Alspec® Commercial range. Available in two frame depths, 101.6mm and 150mm x 44.4mm. Ideal for shopfront use, it is widely favoured by architects and designers for a multitude of applications.

With it’s straight cuts and centre pocket glazing the McArthur not only looks good, but is easy to fabricate and easy to install. McArthur is suitable for a range of glass thicknesses with self draining sub sills that solve water leakage problems. The McArthur also provides a seamless interface with Alspec’s extensive product offer.

Read moreRead less

Key Features

  • Sharp unbroken lines
  • Centre glazed
  • Robust frame
  • Excellent weathering performance
  • 101.6mm and 150mm x 44.5mm framing system
  • 19mm glazing pocket accepts up to 14.5mm single glazed
  • Colour coded glazing wedges for ease of identification
  • Easily adapts to Alspec’s awnings and hinged doors

Technical Specifications

Frame Dimensions

Option 1 101.6 x 44.5mm

Compatible Systems

Windows & Doors Swan Evo™ 45mm/70mm Commercial Shopfront Door
Windows & Doors Torrens 45mm Commercial Shopfront Door
Windows & Doors Awning and Casement Windows
Windows & Doors ProTilt® High Performance Awning/Casement Window
Windows & Doors View-Max® Commercial Sliding Window
Windows & Doors ProGlide® High Performance Sliding Door
Windows & Doors Altitude® Apartment Sliding Door

Maximum Product Performance

SLS (Pa) 3000
ULS (Pa) 7200
WATER (Pa) 1000

Glazing Details

Glass Position Centre
Single Glazed 6 - 14.5mm

Acoustic Performance: Rw (c;ctr)

6.38mm Laminate 32 (-1,-2) dB
12.5mm Vlam Hush 38 (-1,-4) dB

Maximum Recommended Sizes

Height 4200mm
Width 2200mm

Downloads

Tech Manual

Log in to view all files

Customer Technical Memos

Log in to view all files

Wall Charts

Log in to view all files

CAD Drawings

Log in to view all files

3D Revit

Log in to view all files

Typical Configurations

WERS Ratings

Window ID Glazing Frame Uw SHGCw Tvw Air Inf
