Hastings 550 Front Glazed Plant On Sections

The Hastings 550 Front Glazed Plant On System is versatile and flexible allowing glazing adaptors and covers to be fixed to other structures including aluminium, steel or timber.

Tested and Compliant Solutions

The 550 Front Glazed Plant On System is versatile and flexible allowing glazing adaptors and covers to be fixed to other structure including aluminium, steel or timber. With cover adaptors at 50mm they can be used along side the Hastings Framing. Ideal for upmarket residential and commercial applications.

With it’s straight cuts and flush glazing the 550 not only looks good, but is easy to fabricate and easy to install. The 550 glazing suite is suitable for a range of single and double glazed options.

Key Features

  • Sharp unbroken lines
  • Front glazed appearance
  • Robust frame
  • Good weathering performance
  • 4 –12.4mm single glazed and up to 32mm double glazed
  • Easily adapts to Alspec’s hinged doors

Technical Specifications

Frame Dimensions

Option 1 50mm plant on system

Compatible Systems

Windows & Doors Swan Evo™ 45mm/70mm Commercial Shopfront Door
Windows & Doors Torrens 45mm Commercial Shopfront Door

Maximum Product Performance

ULS (Pa) 8000
WATER (Pa) 1000

Glazing Details

Glass Position Front
Single Glazed 6 - 18mm
Double Glazed 24 - 32mm

Maximum Recommended Sizes

Height Dependent on structure
Width Dependent on structure
