Diamond 64mm Stud Partitioning Suite
An economical, light weight, easy to fabricate internal framing system, accommodating a 64mm steel stud with plasterboard and glazing options.
The Diamond suite is a 104.8mm economical, light weight, easy to fabricate internal framing system. The system accommodates 64mm steel stud with plasterboard and glazing options.
The system can be used with a range of standard door frames from 35mm to 45mm and readily complements plasterboard walls.
May be used in conjunction with Alspec’s® range of aluminium skirting.
Technical Specifications
Frame Dimensions
| Option 1 | 104.8 x 25mm |
| Option 2 | 105 x 50mm |
Compatible Systems
| Commercial Framing | Swan Evo™ 45mm/70mm Commercial Shopfront Door |
| Commercial Framing | Skirting Profiles |
Glazing Details
| Glass Position | Centre/Front |
| Single Glazed | 4 - 10.38mm |
Maximum Recommended Sizes
| Height | 2700mm |
| Width | 2400mm |
