Derwent 76mm Centre Pocket Framing
Suitable for residential entrance ways, arcades, glass partitions and offices, the Derwent is the lightest and most slim line of the multi-purpose Alspec® Architectural Suites.
Tested and Compliant Solutions
The Derwent 76mm x35mm Centre Pocket Framing is an ideal economical fixed glazing suite for both internal and external locations. Suitable for residential entrance ways, arcades, glass partitions and offices, the Derwent is the lightest and most slim line of the multi-purpose Alspec Architectural Suites.
With its straight cuts and pocket glazing the Derwent not only looks good, but is easy to fabricate and easy to install. Suitable for a range of glass thicknesses it has self draining sub sills that solve water leakage problems. The Derwent also provides a seamless interface with Alspec’s extensive product offer.
Key Features
- Sharp unbroken lines
- Slimline frame
- 4mm up to 10.38mm glazing options
- Centre pocket framing, reducing the number of beads required thus improving fabrication and installation time
- Various adaptors to easily accept awning, double hung, sliding windows, louvres and Alspec’s hinged doors
Technical Specifications
Frame Dimensions
| Option 1 | 76 x 35mm |
Compatible Systems
| Windows & Doors | Swan Evo™ 45mm/70mm Commercial Shopfront Door |
| Windows & Doors | Torrens 45mm Commercial Shopfront Door |
| Windows & Doors | Awning and Casement Windows |
| Windows & Doors | View-Max® Commercial Sliding Window |
Maximum Product Performance
| SLS (Pa) | 3500 |
| ULS (Pa) | 3500 |
| WATER (Pa) | 600 |
Glazing Details
| Glass Position | Centre |
| Single Glazed | 4 - 10.38mm |
Thermal Performance
| Uw range SG | 4.0 - 5.9 |
| SHGC range SG | 0.34 - 0.77 |
Maximum Recommended Sizes
| Height | 2400mm |
| Width | 2000mm |
