Hastings 550 Front Glazed Plant On Sections
The Hastings 550 Front Glazed Plant On System is versatile and flexible allowing glazing adaptors and covers to be fixed to other structures including aluminium, steel or timber.
Tested and Compliant Solutions
The 550 Front Glazed Plant On System is versatile and flexible allowing glazing adaptors and covers to be fixed to other structure including aluminium, steel or timber. With cover adaptors at 50mm they can be used along side the Hastings Framing. Ideal for upmarket residential and commercial applications.
With it’s straight cuts and flush glazing the 550 not only looks good, but is easy to fabricate and easy to install. The 550 glazing suite is suitable for a range of single and double glazed options.
Key Features
- Sharp unbroken lines
- Front glazed appearance
- Robust frame
- Good weathering performance
- 4 –12.4mm single glazed and up to 32mm double glazed
- Easily adapts to Alspec’s hinged doors
Technical Specifications
Frame Dimensions
| Option 1 | 50mm plant on system |
Compatible Systems
| Windows & Doors | Swan Evo™ 45mm/70mm Commercial Shopfront Door |
| Windows & Doors | Torrens 45mm Commercial Shopfront Door |
Maximum Product Performance
| ULS (Pa) | 8000 |
| WATER (Pa) | 1000 |
Glazing Details
| Glass Position | Front |
| Single Glazed | 6 - 18mm |
| Double Glazed | 24 - 32mm |
Maximum Recommended Sizes
| Height | Dependent on structure |
| Width | Dependent on structure |
