Commercial Framing // Hunter Evo 101.6mm Double Flush Glazed Framing

Introduction

The Hunter Evo 101.6mm Double Flush Glazed Framing is the most versatile and flexible of the Alspec® Commercial Framing Systems. Available in a frame depth of 100mm x 50mm, it is ideal for shopfronts.

With it's straight cuts and flush glazing the Hunter Evo not only looks good, but is easy to fabricate and easy to install. Suitable for a range double glazed options to address the most demanding energy requirements. With self draining sub sills it also solves water leakage problems. The system can be internally or externally glazed along with incorporating the flexibility and appeal of gently curved or faceted frame installations. The Hunter Evo also provides a seamless interface with Alspec's® extensive product offer.

Projects

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Frame Dimensions
Option 1 101.6 x 50mm
Maximum Product Performance
SLS (Pa) 3500
ULS (Pa) 8900
WATER (Pa) 1200
Compatible Systems
Windows & Doors Swan Evo 45mm Commercial Shopfront Door
Windows & Doors Torrens 45mm Commercial Shopfront Door
Windows & Doors 35mm Awning Window
Windows & Doors 50mm Awning Window
Windows & Doors ProTilt High Performance Awning/Casement Window - Single Glazed
Windows & Doors ProGlide High Performance Sliding Door
Windows & Doors Altitude Apartment Sliding Door
Windows & Doors ProVista Sashless Double Hung Window
Glazing Details
Glass Position Front
Double Glazed 15 - 30mm
Acoustic Performance: Rw (c;ctr)
6.38mm/12mm/6.38mm IGU 36 (-1,-5) dB
Maximum Recommended Sizes
Height 4200mm
Width 2400mm
Thermal Performance
Uw range DG 2.4 - 3.6
SHGC range DG 0.17 - 0.64
WERSNatspec

Tested and Compliant Solutions
