Commercial Framing // ecoFRAMEplus 150mm Centre Pocket Double Glazed Framing

Introduction

The ecoFRAMEplus® is the ideal system principally when energy efficiency is paramount. Its versatility allows countless specifications to be achieved, from standard shopfront applications, through to the most challenging structural and energy requirements.

With a frame depth of 150mm x 50mm, ecoFRAMEplus® allows a frame to transform from double to single glazed with ease. Glazing could not be simpler with the colour coded wedges to deal with the many diverse glass options.

With the use of heavy duty mullions the ecoFRAMEplus® 150mm can allow heights to reach and surpass 4.0m depending upon wind loading conditions. Sub sills are recommended for optimum weathering with all ecoFRAMEplus® systems.

Videos

Projects

3D Revit Files

Please log in to access this information

Please log in to access this information

Please log in to access this information

WERS Ratings

Glazing
Frame
TVW
Air Inf
Frame Dimensions
Option 1 150 x 50mm
Maximum Product Performance
SLS (Pa) 2500
ULS (Pa) 3800
WATER (Pa) 1200
Compatible Systems
Windows & Doors Swan Evo 45mm Commercial Shopfront Door
Windows & Doors Torrens 45mm Commercial Shopfront Door
Windows & Doors 35mm Awning Window
Windows & Doors 50mm Awning Window
Windows & Doors ProTilt High Performance Awning/Casement Window - Single Glazed
Windows & Doors View-Max Commercial Sliding Window
Windows & Doors ProGlide High Performance Sliding Door
Windows & Doors Altitude Apartment Sliding Door
Glazing Details
Glass Position Centre
Single Glazed 4 - 14mm
Double Glazed 16 - 28mm
Acoustic Performance: Rw (c;ctr)
6.38mm Laminate 32 (-1,-2) dB
6.38mm/12mm/6.38mm IGU (Max Glass) 36 (-1,-5) dB
Maximum Recommended Sizes
Height 4800mm
Width 2400mm
Thermal Performance
Uw range DG 3.1 - 3.7
SHGC range DG 0.15 - 0.64
WERSNatspec

Tested and Compliant Solutions
